Coxreels LG Series "Little Giant" Spring Driven Hose Reels - LG-LP-115
LG Series "Little Giant" Spring Driven Hose Reels
COXREELS LG Series "Little Giant" is the first lightweight - heavy duty reel on the market. The LG is perfect for commercial or industrial applications where space or budget is limited. It is extremely lightweight and compact and can install almost anywhere. This little giant can accept either a 1/4" or 3/8" hose to tackle the jobs of reels almost double its size.
- Professional grade heavy duty steel construction
- Rolled edges & ribbed discs provide strength & safety
- Leading 2-year manufacturer's limited warranty
- Made in the U.S.A. - Sold & Supported Worldwide
Features
- SWIVEL - Machined from solid brass 90â—¦ full-flow NPT swivel for simple seal maintenance and fast and easy hose installation. No need to remove the reel from its mount.
- RATCHET HUB - Non-corrosive, high strength CoxComposite™ ratchet hub with self lubricating bronze bearings secures hose at desired length.
- CNC SPUN DISCS - Heavy duty CNC robotically spun and ribbed discs with rolled edges for greater strength, durability, hose protection and operator safety.
- 12GA STEEL BASE - Solid one piece, 12GA steel base and support post for maximum stability. Compact & lightweight spring driven hose reel.
- GROMMET - CoxComposite™ grommet with continuous radius design that does not pinch or catch the hose during operation.
- OTHER FEATURES INCLUDE - long lasting, chip resistant and rust inhibiting CPC powder coat finish, adjustable solid rubber hose stop, and sturdy permanently lubricated precision bearings.
Specifications
MODEL |
I.D |
O.D |
LENGTH |
HOSE |
MAX PSI |
SHIP WEIGHT (LBS) |
OVERALL DIMENSIONS (W) (H) (L) |
MOUNTING PATTERN (M) (N) |
BASE (X) (Y) |
LG-LP-115 |
1/4" |
1/2" |
15' |
Yes |
300 |
9 |
5.25"(W) 10.63"(H) 10.5"(L) |
2.5"(M) 6"(N) |
4.69"(X) 8.38"(Y) |
LG-LP-125 |
1/4" |
1/2" |
25' |
Yes |
300 |
11 |
5.25"(W) 10.63"(H) 10.5"(L) |
2.5"(M) 6"(N) |
4.69"(X) 8.38"(Y) |
LG-LP-310 |
3/8" |
5/8" |
10' |
Yes |
300 |
9 |
5.25"(W) 10.63"(H) 10.5"(L) |
2.5"(M) 6"(N) |
4.69"(X) 8.38"(Y) |
LG-LP-320 |
3/8" |
5/8" |
20' |
Yes |
300 |
11 |
5.25"(W) 10.63"(H) 10.5"(L) |
2.5"(M) 6"(N) |
4.69"(X) 8.38"(Y) |
LG-LPL-115 |
1/4" |
1/2" |
15' |
No |
300 |
8 |
5.25"(W) 10.63"(H) 10.5"(L) |
2.5"(M) 6"(N) |
4.69"(X) 8.38"(Y) |
LG-LPL-125 |
1/4" |
1/2" |
25' |
No |
300 |
8 |
5.25"(W) 10.63"(H) 10.5"(L) |
2.5"(M) 6"(N) |
4.69"(X) 8.38"(Y) |
LG-LPL-310 |
3/8" |
5/8" |
10' |
No |
300 |
8 |
5.25"(W) 10.63"(H) 10.5"(L) |
2.5"(M) 6"(N) |
4.69"(X) 8.38"(Y) |
LG-LPL-320 |
3/8" |
5/8" |
20' |
No |
300 |
8 |
5.25"(W) 10.63"(H) 10.5"(L) |
2.5"(M) 6"(N) |
4.69"(X) 8.38"(Y) |
What Our Experts Think
-
Compact & Efficient: Designed for tight spaces, the "Little Giant" offers compact storage without compromising performance, making it perfect for smaller work areas.
-
Spring-Driven Retraction: Smooth and automatic retraction system for effortless hose storage and reduced manual handling.
-
Low-Pressure Capability: Ideal for handling hoses up to 300 PSI, suitable for air, water, or light-duty fluid transfer applications.
-
Durable Construction: Built with high-quality materials to withstand everyday wear and tear, ensuring long-lasting reliability.
-
Space-Saving Design: Small footprint yet highly efficient, optimizing workspace without cluttering the area.
-
Versatile Mounting: Flexible installation options for wall, ceiling, or floor mounting, offering adaptable solutions for various environments.
-
Corrosion-Resistant Finish: Ensures durability and protection from rust, enhancing performance in challenging conditions.
Q&A
Q: What is the Coxreels LG Series "Little Giant" Spring Driven Hose Reel - LG-LP-115?
A: The Coxreels LG-LP-115 is a compact, spring-driven hose reel from the "Little Giant" series, designed for low-pressure hose applications. It offers reliable, space-saving hose management with automatic retraction for a tidy workspace.
Q: What is the hose capacity of this reel?
A: The LG-LP-115 can hold up to 115 feet of low-pressure hose, making it ideal for a wide range of light-duty industrial, commercial, and residential uses.
Q: How does the spring-driven mechanism work?
A: The reel features an automatic spring rewind system, which retracts the hose smoothly after use, reducing manual effort and preventing hose tangling.
Q: Is the reel durable?
A: Yes, the LG Series is constructed with high-quality steel and a corrosion-resistant finish, ensuring long-lasting durability in various environments.
Q: Is this reel easy to install?
A: Yes, the LG-LP-115 is designed for easy installation with multiple mounting options, including wall, floor, or ceiling mounting, to suit different workspace needs.
Q: What are typical applications for this reel?
A: This reel is perfect for light-duty tasks in automotive shops, workshops, and residential areas, where low-pressure hose management is required.
Maintenance Tips
-
Model: LG-LP-115
-
Hose Capacity: 50 feet of 1/4” or 3/8” hose
-
Pressure Rating: Ideal for low-pressure applications, typically up to 3000 PSI
-
Construction: Heavy-duty steel frame with a powder-coated finish for durability and corrosion resistance
-
Mounting Type: Wall, floor, or ceiling mounting options for flexible installation
-
Drive Mechanism: Spring-driven automatic rewind for easy and efficient hose retraction
-
Roller Design: Features smooth, multi-position guide arm rollers to reduce wear and ensure smooth hose payout
-
Swivel Inlet: Full-flow swivel for uninterrupted fluid delivery and reduced wear on hoses
-
Applications: Perfect for air, water, or low-pressure fluid applications in workshops, garages, and light industrial settings
