| Accessories (sold separately) |
| Door panel stainless steel |
RD2474 (right & left hinge) |
| Handle kit Contemporary square fine, aluminium |
AHD5RDSF |
| Handle kit Contemporary square fine, black |
AHD5RDSFB |
| Handle kit Professional round flush |
25921 |
| Joiner kit |
AJRS74LR |
| Toe kick stainless steel 23" |
AKRS2304 |
| Toe kick stainless steel 47" |
AKRS4704 |
| Toe kick stainless steel 71" |
AKRS7104 |
| Water filter replacement |
847200 |
| Capacity |
| Total gross capacity |
10.7cu ft |
| Volume freezer |
10.7cu ft |
| Consumption |
| Energy usage |
379kWh/year |
| Features |
| Adjustable door shelves |
2 |
| Freezer Features |
| Freezer bins |
4 |
| Ice making rate per day |
2.2lbs |
| Installation Dimensions |
| Minimum inside width of cabinetry frame |
23 5 / 8 " |
| Minimum internal depth of cabinetry |
24 " |
| Minimum internal height of cabinetry |
74 " |
| Performance |
| Variable food modes |
Chill |
| Variable temperature zones |
3 |
| Power requirements |
| Rated current |
10A |
| Supply frequency |
60Hz |
| Supply voltage |
115V |
| Product dimensions |
| Depth |
22 11 / 16 " |
| Height |
73 5 / 8 " |
| Width |
23 5 / 16 " |
| Warranty |
| Parts and labor |
2 years |
| Sealed system parts only |
5 years |
Manual
What our Experts Think
-
Triple Zone Freezing – Separate compartments for optimal food preservation.
-
Integrated Design – Seamlessly blends into your kitchen cabinetry.
-
24" Space-Saving Size – Ideal for compact kitchens or as an additional freezer.
-
Built-In Ice Maker – Convenient access to fresh ice anytime.
-
Smart Touch Controls – Effortless temperature management for precise cooling.
Q&A
Q: What is triple-zone cooling?
A: This freezer offers three independent temperature zones, allowing you to store different types of frozen food at optimal conditions.
Q: Is panel customization available?
A: Yes, this model is panel-ready, allowing you to customize the exterior to match your cabinetry (panel sold separately).
Q: Does this freezer require a water connection?
A: Yes, a plumbed water connection is required for the automatic ice maker.
Q: Is professional installation recommended?
A: Yes, professional installation is recommended to ensure proper integration and functionality.
Maintenance Tips
-
Clean Seals Regularly: Wipe door gaskets with a damp cloth to ensure a tight seal and prevent energy loss.
-
Defrost When Needed: Although frost-free, check for ice buildup and follow manufacturer guidelines if defrosting is required.
-
Keep Vents Clear: Ensure proper airflow by not blocking internal vents with food items.
-
Wipe Interior & Exterior: Use a mild detergent to clean shelves, drawers, and surfaces. Avoid abrasive cleaners.
-
Change Water Filter: Replace the ice maker filter as recommended to maintain ice quality.
-
Monitor Temperature Settings: Keep at optimal freezing temperatures (-18°C/0°F) for efficiency and food preservation.
