Spring USA SM-360R Spring USA Induction DOT, Hold-only Rnd Induction Range 360W - SPSM360R

Spring USA SM-360R Spring USA Induction DOT, Hold-only Rnd Induction Range 360W - SPSM360R

The Spring USA Induction DOT round induction range is the perfect solution for any buffet, restaurant, breakfast bar, or catered event for precise warming and holding of served foods. Compact in size with just a 9.1" diameter, these ranges take up minimal countertop space for either drop-in, flushmount, or countertop induction while providing industry-leading induction technology by Spring USA. With exclusive SmartScan technology, the Induction DOT provides over/under voltage protection, vessel size/ type recognition to protect from warping or food from burning. Automatic pan recovery seamlessly adjusts and recognizes vessels without losing connection as they lift from the surface. Equipped with 4 heat settings and 360 watts of power, you can easily daisy-chain up to 4 units on a 15-amp circuit. The brushed stainless steel rim removes the need for mounting brackets when dropped-in to any furniture or countertop. For flush-mount installation, use available undermount bracket. With just 1.18" (3cm) clearance needed between units, you can easily fit multiple units into/ on a standard table or countertop. A removable control box with 4 soft-touch controls can be installed wherever needed. The DOT is able to be used as a countertop induction unit with the compatible Wynwood stand (sold separately). Just 4.2 lbs, you can easily pick up the portable Induction DOT for off-premise catering, flexible buffet set ups, and more. Low profile design, only 9.1” in diameter 3 different configurations: countertop, drop-in, or flush-mount Daisy-chain up to 4 units on a single 15-amp circuit Removable control box with touch controls & indicator lights 4 Power levels: low, low-med, med-high, high Rugged, easy to clean, 5-mm tempered glass top Sleek, round housing Stainless-steel rim Non-skid, non-scratch footing NSF-Certified, UL Rated

What our Experts Think

• Compact Design: With a diameter of 9.1 inches and a height of 3.125 inches, the SM-360R has a low-profile design that saves valuable countertop space.

• Flexible Installation: This induction range offers three installation options: countertop, drop-in, or flush-mount, adapting to various kitchen configurations and requirements.

• Efficient Power Usage: Operating at 360 watts, the SM-360R is energy-efficient, allowing up to four units to be daisy-chained on a single 15-amp circuit, optimizing electrical usage.

• User-Friendly Controls: Equipped with a removable control box featuring four soft-touch controls and indicator lights, users can easily adjust settings to maintain desired food temperatures.

• SmartScan Technology: Incorporates SmartScan technology that provides over/under voltage protection, recognizes vessel size and type to prevent warping, and offers automatic pan recovery when vessels are lifted.

• Durable Construction: Features a 5-mm thick tempered glass top that is both rugged and easy to clean, ensuring longevity and maintaining a professional appearance.

• Safety Features: Includes non-skid, non-scratch footing to prevent movement and protect surfaces, enhancing safety during operation.

• Certifications: The SM-360R is NSF-certified, ETL-listed, and UL-rated, meeting rigorous standards for safety and performance in commercial foodservice environments.

Q&A

Q: What is the purpose of the Spring USA SM-360R Induction Range?
A: The SM-360R is a compact induction range designed exclusively for holding and warming pre-cooked food at precise temperatures, not for cooking.

Q: What are the dimensions and weight of the SM-360R?
A: The unit measures 9.125 inches in diameter and 3.125 inches in height, with a weight of approximately 4.2 lbs

Q: What heating options does the SM-360R offer?
A: It provides four heat settings: low, low-medium, medium-high, and high, with a maximum temperature of 185°F (85°C).

Q: How does the SM-360R ensure safety and efficiency?
A: It features SmartScan technology for over/under voltage protection, vessel size/type recognition to prevent warping and food burning, and automatic pan recovery when vessels are lifted.

Q: What are the electrical requirements for the SM-360R?
A: It operates on 120 V, 60 Hz, consuming 360 W and 3 amps, with a NEMA 5-15P plug.

Q: Can multiple SM-360R units be connected together?
A: Yes, up to four units can be daisy-chained on a single 15-amp circuit.

Q: What installation options are available for the SM-360R?
A: It can be used as a countertop unit, drop-in, or flush-mount, offering flexibility to suit various setups.

Q: What certifications does the SM-360R hold?
A: It is NSF certified, UL 197 listed, and CSA C22.2 #109 (cETL) rated, ensuring compliance with recognized safety and performance standards.

Q: What warranty does Spring USA offer for the SM-360R?
A: Spring USA provides a one-year limited warranty with an overnight exchange option within the continental U.S., covering manufacturing defects from the date of invoice.

Maintenance Tips

• Compact Design: With a diameter of 9.125 inches and a height of 3.125 inches, the SM-360R is designed to fit seamlessly into countertops or serve as a standalone unit.

• Flexible Installation: This induction range offers three installation options: countertop, drop-in, or flush-mount, providing adaptability to various service setups.

• Power and Efficiency: Equipped with 360 watts of power, it offers four heat settings—low, low-medium, medium-high, and high—to accommodate different food warming requirements.

• Daisy-Chaining Capability: Multiple units can be connected (daisy-chained) on a single 15-amp circuit, allowing for efficient expansion of warming stations without overloading electrical circuits.
